0760555106
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Impact 76055 ROHS3Compliant Vertical GENERAL PURPOSE Connector Header, Male Pins UL94V-0 -55C~85C 30V 24.8mm
PDF
/
Inventory: 7645
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Additional Feature IMPACT, POLARIZED
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.053 1.35mm
Total Number of Contacts 150
Orientation Vertical
Depth 24.8mm
Gender Male
Number of Rows 15
Color Black
Number of Positions 150
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Impact 76055
Packaging Tray
Operating Temperature -55°C~85°C
Number of Columns 10
Contact Layout, Typical 50 Differential Pairs
Connector Style Impact, Guide Right
Max Voltage Rating (AC) 30V
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Number of Positions Loaded All
Physical
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 15 Weeks
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 18.9mm
