0760351903
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
High Speed / Modular Connectors I-TRAC 15 ROW BP ASS BP ASSY - 9 COL OPEN
PDF
/
Inventory: 6597
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 33.15mm
Technical
Number of Columns 9
Connector Style I-Trac
Max Voltage Rating (AC) 120V
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Number of Positions Loaded All
Depth 32.2mm
Orientation Vertical
Total Number of Contacts 270
Pitch 3.7mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature PANEL MOUNTABLE
Number of Rows 15
Color Black
Number of Positions 270
Connector Type Header, Male Pins
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series GbX I-Trac 76035
Packaging Tray
Operating Temperature -55°C~80°C
Physical
Housing Material Polymer
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold, Tin
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 8 Weeks
