0759107633
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
High Speed / Modular Connectors I-Trac 11 Row RAM As ow RAM Assy Sn Only
PDF
/
Inventory: 5762
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 29.6mm
Technical
Number of Columns 6
Connector Style I-Trac
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Number of Positions Loaded All
Orientation Right Angle
Total Number of Contacts 132
Pitch 1.85mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 120V
Number of Rows 11
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 80°C
Number of Positions 132
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series GbX I-Trac 75910
Packaging Tray
Physical
Housing Material Polymer
Mounting Type Board Edge, Through Hole, Right Angle
Mount Edge, Through Hole
Contact Plating Gold, Tin
Contact Material NOT SPECIFIED
