0758324205
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
High Speed / Modular Connectors GbX 2-Pair 25-Col Ri ight End LF BP Ass'y
PDF
/
Inventory: 8212
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length 52.53mm
Technical
Number of Columns 25
Contact Layout, Typical 50 Differential Pairs
Connector Style GbX Guide Right
Max Voltage Rating (AC) 120V
Housing Color Grey
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Current Rating 1A
Number of Positions Loaded All
Depth 13.7mm
Orientation Vertical
Total Number of Contacts 100
Pitch 0.073 1.85mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 4
Color Gray
Number of Positions 100
Connector Type Header, Male Pins
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Shielded
JESD-609 Code e3
Series GbX 75832
Packaging Tube
Operating Temperature -55°C~85°C
Physical
Housing Material Polymer
Material Stainless Steel
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold, Tin
