0758270504
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
High Speed / Modular Connectors GbX 2-Pair 5-Col. Op ol. Open BP Assembly
PDF
/
Inventory: 9164
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mount Through Hole
Mounting Type Through Hole
Housing Material Polymer
Technical
Packaging Tray
Series GbX 75827
Feature Shielded
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 20
Color Gray
Number of Rows 4
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.073 1.85mm
Total Number of Contacts 20
Orientation Vertical
Depth 13.7mm
Number of Positions Loaded All
Current Rating 1A
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Housing Color Grey
Max Voltage Rating (AC) 120V
Connector Style GbX
Contact Layout, Typical 10 Differential Pairs
Number of Columns 5
Dimensions
Length 9.1mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
