0757102006

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description Conn Daughter Card RCP 132 POS 3.7mm Press Fit RA Thru-Hole GbX I-Trac? Tray
PDF
/
Inventory: 5806
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Length 29.6mm

Technical

Number of Columns 6
Max Voltage Rating (DC) 120V
Connector Style I-Trac, Guide Left
Max Voltage Rating (AC) 120V
Contact Resistance 10mOhm
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Number of Positions Loaded All
Depth 34.8mm
Orientation Right Angle
Total Number of Contacts 132
Pitch 3.7mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 11
Color Black
Number of Positions 132
Connector Type Receptacle, Female Sockets
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series GbX I-Trac 75710
Packaging Tray
Operating Temperature -55°C~80°C

Physical

Housing Material Polymer
Mounting Type Board Edge, Through Hole, Right Angle
Mount Edge, Through Hole
Contact Plating Gold, Lead, Tin
Contact Material NOT SPECIFIED
