0754654204
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
High Speed / Modular Connectors GbX 4-Pair L-Series 25-Col Right BP Assy
PDF
/
Inventory: 958
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Material Stainless Steel
Housing Material Polymer
Technical
Packaging Tray
Series GbX 75465
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 275
Color Gray
Number of Rows 11
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.073 1.85mm
Total Number of Contacts 275
Orientation Vertical
Depth 24.8mm
Number of Positions Loaded All
Current Rating 1A
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Housing Color Grey
Number of Circuits 110
Max Voltage Rating (AC) 120V
Connector Style GbX Guide Right
Number of Columns 25
Dimensions
Length 46.1mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
