0752372214
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
GbX 75237 ROHS3Compliant Straight Shielded Connector Header, Male Pins UL94V-0 1mOhm 105C 120V
PDF
/
Inventory: 4390
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Housing Material Polymer
Technical
Packaging Tray
Series GbX 75237
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Header, Male Pins
Number of Positions 250
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Gray
Number of Rows 10
Voltage - Rated 120V
Pitch 0.073 1.85mm
Orientation Straight
Depth 31mm
Number of Positions Loaded All
Contact Finish Gold
Housing Color Grey
Contact Resistance 1mOhm
Max Voltage Rating (AC) 120V
Connector Style GbX Guide Left
Contact Layout, Typical 125 Differential Pairs
Number of Columns 25
Dimensions
Length 52.53mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
