0752354763
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
GbX 75235 ROHS3Compliant Straight Shielded Connector Header, Male Pins UL94V-0 1mOhm 105C 120V
PDF
/
Inventory: 5870
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Housing Material Polymer
Technical
Packaging Tray
Series GbX 75235
Feature Shielded
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Header, Male Pins
Number of Positions 56
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Gray
Number of Rows 8
Voltage - Rated 120V
Pitch 0.073 1.85mm
Orientation Straight
Depth 24.8mm
Number of Positions Loaded All
Contact Finish Gold
Housing Color Grey
Contact Resistance 1mOhm
Max Voltage Rating (AC) 120V
Connector Style GbX Guide Right
Contact Layout, Typical 28 Differential Pairs
Number of Columns 7
Dimensions
Length 19.23mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
