0751981014

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description VHDM Lite 75198 Non-RoHS Compliant Vertical GENERAL PURPOSE Connector Header, Male Pins UL94V-0 10mOhm -55C~105C 1A
PDF
/
Inventory: 7552
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Contact Material NOT SPECIFIED
Contact Plating Gold, Lead, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polymer

Technical

Operating Temperature -55°C~105°C
Packaging Tube
Series VHDM Lite 75198
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 80
Color Black
Number of Rows 8
Additional Feature PANEL MOUNTABLE
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 3A
Pitch 0.079 2.00mm
Total Number of Contacts 80
Orientation Vertical
Depth 21.6mm
Number of Positions Loaded All
Current Rating 1A
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Resistance 10mOhm
Max Voltage Rating (AC) 120V
Connector Style VHDM, Guide Left
Number of Columns 10

Dimensions

Length 27mm
Contact Finish Thickness 30.0μin 0.76μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
