0751952503

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description High Speed / Modular Connectors VHDM Lite 6R 25C Sig Signal End BP 4.25mm
PDF
/
Inventory: 5915
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Length 57mm

Technical

Number of Columns 25
Connector Style VHDM, Guide Left
Max Voltage Rating (AC) 120V
Number of Circuits 150
Contact Resistance 10mOhm
Housing Color Black
Contact Finish Gold
Current Rating 2A
Number of Positions Loaded All
Depth 17.1mm
Orientation Vertical
Pitch 0.079 2.00mm
Current Rating (Amps) 2A
Number of Rows 6
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 150
Connector Type Header, Male Pins
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series VHDM Lite 75195
Packaging Tube
Operating Temperature -55°C~105°C

Physical

Housing Material Polymer
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold, Lead, Tin

Supply Chain

Factory Lead Time 6 Weeks
