0740601003

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description Conn Hard Metric HDR 80 POS 2mm Press Fit ST Thru-Hole VHDM? Tube
PDF
/
Inventory: 6538
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Max Voltage Rating (AC) 120V
Connector Style VHDM
Number of Columns 10
Contact Resistance 10mOhm
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Current Rating 3A
Number of Positions Loaded All
Depth 21.6mm
Orientation Vertical
Total Number of Contacts 80
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature PANEL MOUNTABLE
Voltage - Rated 120V
Number of Rows 8
Color Black
Number of Positions 80
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Shielded
Series VHDM 74060
Packaging Tube
Operating Temperature -55°C~105°C

Dimensions

Length 20mm
Contact Finish Thickness 30.0μin 0.76μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0

Physical

Housing Material Polymer
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold, Lead, Tin
Contact Material NOT SPECIFIED
