0737801234
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
HDM (High Density Metric) 73780 ROHS3Compliant Vertical GENERAL PURPOSE Connector Receptacle, Female Sockets UL94V-0 10mOhm -55C~105C 250V
PDF
/
Inventory: 6054
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper, Tin
Contact Plating Gold, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Technical
Operating Temperature -55°C~105°C
Packaging Tube
Series HDM (High Density Metric) 73780
JESD-609 Code e3
Feature Stackable
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Female Sockets
Number of Positions 144
Color Black
Number of Rows 6
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 144
Orientation Vertical
Depth 13.4mm
Number of Positions Loaded All
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Resistance 10mOhm
Max Voltage Rating (AC) 250V
Connector Style HDM
Number of Columns 24
Connector Usage Daughtercard
Dimensions
Length 48.17mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
