0737800253
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Board to Board & Mezzanine Connectors 2mm HDM DC Stacking ng Mod ST 30Au 72Ckt
PDF
/
Inventory: 3364
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 24.17mm
Technical
Connector Usage Daughtercard
Number of Columns 12
Connector Style HDM
Max Voltage Rating (AC) 250V
Number of Circuits 72
Contact Resistance 10mOhm
Housing Color Black
Contact Finish Gold
Current Rating 1A
Number of Positions Loaded All
Depth 13.4mm
Orientation Vertical
Pitch 0.079 2.00mm
Current Rating (Amps) 1A
Voltage - Rated 250V
Number of Rows 6
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 72
Connector Type Receptacle, Female Sockets
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Stackable
Series HDM (High Density Metric) 73780
Packaging Tube
Operating Temperature -55°C~105°C
Physical
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Copper, Tin
Supply Chain
Factory Lead Time 10 Weeks
