0736432100
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
High Speed / Modular Connectors HDM 72 POS. END WALL BACKPLANE ASSEMBLY
PDF
/
Inventory: 5689
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Technical
Number of Columns 12
Connector Style HDM
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Number of Positions Loaded All
Total Number of Contacts 72
Pitch 0.079 2.00mm
Current Rating (Amps) 1A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 250V
Number of Rows 6
Color Black
Number of Positions 72
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series HDM (High Density Metric) 73643
Packaging Tube
Operating Temperature -55°C~105°C
Physical
Mounting Type Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 7 Weeks
