0465623005
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Molex EXTREME TEN60POWER Series 30 Way 3 Row Straight Heavy Duty Power Connector Press Fit Female Connector
PDF
/
Inventory: 2155
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Technical
Contact Layout, Typical 24 Signal, 6 Power
Connector Style EXTreme Ten60Power
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 30
Contact Finish Gold
Current Rating 60A
Number of Positions Loaded All
Orientation Vertical
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature POLARIZED
Voltage - Rated 600V
Number of Rows 3
Color Black
Connector Type Receptacle, Female Sockets and Blade Sockets
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Mating Guide
JESD-609 Code e3
Series EXTreme Ten60Power 46562
Packaging Tray
Operating Temperature -40°C~105°C
Physical
Shell Material POLYETHYLENE
Mounting Type Through Hole
Mount Press Fit, Through Hole
Contact Material COPPER
Supply Chain
Factory Lead Time 14 Weeks
