0459856431

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description EXTreme LPHPower 45985 ROHS3Compliant Right Angle Board Guide Mating Guide Connector Plug, Center Strip Contacts UL94V-0 105C 27A 250V
PDF
/
Inventory: 7166
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material Bronze
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Polymer

Technical

Operating Temperature -40°C~105°C
Packaging Tray
Series EXTreme LPHPower 45985
Feature Board Guide, Mating Guide
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 50
Termination Solder
Connector Type Plug, Center Strip Contacts
Number of Positions 26
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Black
Number of Rows 2
Pitch 0.050 1.27mm
Orientation Right Angle
Depth 16.28mm
Number of Positions Loaded All
Current Rating 27A
Contact Finish Gold
Number of Circuits 22
Max Voltage Rating (AC) 250V
Connector Style LPHPower
Number of Ports 1
Contact Layout, Typical 20 Signal, 6 Power

Dimensions

Length 60.74mm
Contact Finish Thickness 30.0μin 0.76μm

Compliance

Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
