0459856412

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description Conn LPH PL 6Power/12Signal POS 2.5mm/2.54mm Solder RA Thru-Hole 42 Terminal 3/1 Port EXTreme LPHPower? Tray
PDF
/
Inventory: 981
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material BRASS
Mounting Type Through Hole, Right Angle

Technical

Operating Temperature -40°C~105°C
Packaging Tray
Series EXTreme LPHPower 45985
JESD-609 Code e3
Feature Board Guide, Mating Guide
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Plug, Center Strip Contacts
Number of Positions 18
Color Black
Number of Rows 2
Additional Feature POLARIZED, SHROUDED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Pitch 0.050 1.27mm
Total Number of Contacts 18
Number of Positions Loaded All
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender MALE
UL Flammability Code 94V-0
Connector Style LPHPower
Contact Layout, Typical 12 Signal, 6 Power

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
