0459856252
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
EXTreme LPHPower 45985 ROHS3Compliant Right Angle GENERAL PURPOSE Connector Plug, Center Strip Contacts UL94V-0 -40C~105C 27A 250V
PDF
/
Inventory: 7585
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Bronze
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Polymer
Technical
Operating Temperature -40°C~105°C
Packaging Tray
Series EXTreme LPHPower 45985
JESD-609 Code e3
Feature Mating Guide
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 58
Termination Solder
Connector Type Plug, Center Strip Contacts
Number of Positions 34
Color Black
Number of Rows 2
Additional Feature POLARIZED, SHROUDED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Pitch 0.050 1.27mm
Total Number of Contacts 34
Orientation Right Angle
Depth 16.28mm
Number of Positions Loaded All
Current Rating 27A
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender MALE
UL Flammability Code 94V-0
Max Voltage Rating (AC) 250V
Connector Style LPHPower
Number of Ports 1
Contact Layout, Typical 28 Signal, 6 Power
Dimensions
Length 65.82mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
