0459851432

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description Conn LPH PL 10Power/20Signal POS Solder RA Thru-Hole 70 Terminal 1 Port EXTreme LPHPower? Tray
PDF
/
Inventory: 8400
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material BRASS
Mount Through Hole
Mounting Type Through Hole, Right Angle

Technical

Operating Temperature -40°C~105°C
Packaging Tray
Series EXTreme LPHPower 45985
JESD-609 Code e3
Feature Board Guide, Mating Guide
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Plug, Center Strip Contacts
Number of Positions 30
Color Black
Number of Rows 2
Gender Male
Voltage - Rated 250V
Additional Feature POLARIZED, SHROUDED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Pitch 0.050 1.27mm
Total Number of Contacts 30
Orientation Right Angle
Number of Positions Loaded All
Current Rating 20A
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Connector Style LPHPower
Max Voltage Rating (DC) 250.25kV
Halogen Free Low Halogen
Contact Layout, Typical 20 Signal, 10 Power
Glow Wire Compliant Non-compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
