0459851151

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description Conn LPH HDR 10Power/28Signal POS 2.5mm/2.54mm Solder RA Thru-Hole 78 Terminal 5/1 Port Tray
PDF
/
Inventory: 9431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Technical

Contact Layout, Typical 28 Signal, 10 Power
Number of Ports 1
Connector Style LPHPower
Max Voltage Rating (AC) 250V
Number of Circuits 34
UL Flammability Code 94V-0
Contact Gender MALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Current Rating 20A
Number of Positions Loaded All
Depth 16.3mm
Orientation Right Angle
Total Number of Contacts 38
Pitch 0.050 1.27mm
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature POLARIZED, SHROUDED
Number of Rows 2
Color Black
Number of Positions 38
Connector Type Plug, Center Strip Contacts
Termination Solder
Number of Terminations 78
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series EXTreme LPHPower 45985
Packaging Tray
Operating Temperature -40°C~105°C

Physical

Housing Material Polymer
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Bronze

Supply Chain

Factory Lead Time 8 Weeks
