0459846241
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Heavy Duty Power Connectors LPH Rcpt Assy RtAn 0 06 Pwr 24 Sig Guides
PDF
/
Inventory: 6007
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Technical
Contact Layout, Typical 24 Signal, 6 Power
Number of Ports 1
Connector Style LPHPower
Max Voltage Rating (AC) 250V
Number of Circuits 26
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Current Rating 27A
Number of Positions Loaded All
Depth 18.6mm
Orientation Right Angle
Total Number of Contacts 30
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature POLARIZED
Number of Rows 2
Color Black
Number of Positions 30
Connector Type Receptacle, Outer Shroud Contacts
Termination Solder
Number of Terminations 54
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Guide Pin
JESD-609 Code e3
Series EXTreme LPHPower 45984
Packaging Tray
Operating Temperature -40°C~105°C
Physical
Housing Material Polymer
Shell Material POLYETHYLENE
Mounting Type Through Hole, Right Angle
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
