0459844472
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Conn LPH RCP 4Power/36Signal POS 2.5mm/2.54mm Solder RA Thru-Hole 56 Terminal 2/1 Port Tray
PDF
/
Inventory: 9095
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Bronze
Mount Through Hole
Mounting Type Through Hole, Right Angle
Shell Material POLYETHYLENE
Technical
Operating Temperature -40°C~105°C
Packaging Tray
Series EXTreme LPHPower 45984
JESD-609 Code e3
Feature Board Guide, Guide Pin
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Outer Shroud Contacts
Number of Positions 40
Color Black
Number of Rows 2
Voltage - Rated 250V
Additional Feature POLARIZED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Total Number of Contacts 40
Orientation Right Angle
Number of Positions Loaded All
Current Rating 30A
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
UL Flammability Code 94V-0
Empty Shell NO
Max Voltage Rating (AC) 250V
Connector Style LPHPower
Halogen Free Low Halogen
Contact Layout, Typical 36 Signal, 4 Power
Glow Wire Compliant Non-compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
