0459844383
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
EXTreme LPHPower 45984 ROHS3Compliant Right Angle GENERAL PURPOSE Connector Receptacle, Outer Shroud Contacts UL94V-0 -40C~105C 30A 250V
PDF
/
Inventory: 6332
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Shell Material POLYETHYLENE
Housing Material Polymer
Technical
Operating Temperature -40°C~105°C
Packaging Tray
Series EXTreme LPHPower 45984
JESD-609 Code e3
Feature Board Guide
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 60
Termination Solder
Connector Type Receptacle, Outer Shroud Contacts
Number of Positions 44
Color Black
Number of Rows 2
Additional Feature POLARIZED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Total Number of Contacts 44
Orientation Right Angle
Depth 18.6mm
Number of Positions Loaded All
Current Rating 30A
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
UL Flammability Code 94V-0
Empty Shell NO
Max Voltage Rating (AC) 250V
Connector Style LPHPower
Number of Ports 1
Contact Layout, Typical 40 Signal, 4 Power
Dimensions
Length 58.93mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
