0459844313

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description Conn LPH RCP 4Power/12Signal POS 2.5mm/2.54mm Solder RA Thru-Hole 32 Terminal 2/1 Port Tray
PDF
/
Inventory: 8463
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Length 41.13mm

Technical

Contact Layout, Typical 12 Signal, 4 Power
Number of Ports 1
Connector Style LPHPower
Max Voltage Rating (AC) 250V
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 16
Contact Finish Gold
Current Rating 30A
Number of Positions Loaded All
Depth 18.6mm
Orientation Right Angle
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature POLARIZED
Number of Rows 2
Color Black
Connector Type Receptacle, Outer Shroud Contacts
Termination Solder
Number of Terminations 32
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide
JESD-609 Code e3
Series EXTreme LPHPower 45984
Packaging Tray
Operating Temperature -40°C~105°C

Physical

Housing Material Polymer
Shell Material POLYETHYLENE
Mounting Type Through Hole, Right Angle
Mount Through Hole

Supply Chain

Factory Lead Time 7 Weeks
