0459841233

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description EXTreme LPHPower 45984 ROHS3Compliant Right Angle GENERAL PURPOSE Connector Receptacle, Outer Shroud Contacts UL94V-0 -40C~105C 20A 250V
PDF
/
Inventory: 2668
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Technical

Contact Layout, Typical 20 Signal, 10 Power
Number of Ports 1
Connector Style LPHPower
Max Voltage Rating (AC) 250V
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 30
Contact Finish Gold
Current Rating 20A
Number of Positions Loaded All
Depth 18.6mm
Orientation Right Angle
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature POLARIZED
Number of Rows 2
Color Black
Connector Type Receptacle, Outer Shroud Contacts
Termination Solder
Number of Terminations 70
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Guide Pin
Series EXTreme LPHPower 45984
Packaging Tray
Operating Temperature -40°C~105°C

Physical

Housing Material Polymer
Shell Material POLYETHYLENE
Mounting Type Through Hole, Right Angle
Mount Through Hole

Supply Chain

Factory Lead Time 8 Weeks
