CPH38W23MARARK9X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
CONN PLUG COMPACT PCI 38POS PCB
PDF
/
Inventory: 5352
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Plastic
Technical
Operating Temperature -55°C~125°C
Packaging Tray
Published 2005
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Plug, Male Pins
Number of Positions 38
Color Gray
Gender Male
Additional Feature ROHS COMPLIANT
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Mixed Contacts YES
Total Number of Contacts 38
Number of Positions Loaded All
Current Rating 40A
Number of Conductors ONE
Reference Standard UL,VDE,CSA
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 3.591 inch
Body Depth 1.122 inch
Rated Current (Signal) 5A
Contact Style RND PIN-SKT
Contact Resistance 4mOhm
Insulation Resistance 5000000000Ohm
Body/Shell Style RECEPTACLE
Dielectric Withstanding Voltage 1400VAC V
Connector Style CompactPCI?
Durability 250 Cycles
Contact Layout, Typical 15 Single Signal, 23 Power
Contact Arrangement S15P23
Dimensions
Contact Finish Thickness Flash
Length - Termination 0.102 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
