CPH38W23FGE3SK9X

Conec
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description CONN CPCI 38POS RCPT STR PRESFIT
PDF
/
Inventory: 7875
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Length - Termination 0.154 inch
Contact Finish Thickness Flash

Technical

Contact Arrangement S15P23
Contact Layout, Typical 15 Single Signal, 23 Power
Durability 50 Cycles
Connector Style CompactPCI?
Insulation Resistance 5000000000Ohm
Contact Style RND PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.74 inch
Body Breadth 0.5 inch
Body Length or Diameter 3.701 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Current Rating 40A
Number of Positions Loaded All
Total Number of Contacts 38
Mixed Contacts YES
Subcategory Headers and Edge Type Connectors
Gender Female
Color Gray
Number of Positions 38
Connector Type Receptacle, Female Sockets
Termination Press-Fit
Part Status Active
Pbfree Code yes
Published 2005
Packaging Tray
Operating Temperature -55°C~125°C

Physical

Housing Material Plastic
Mounting Type Through Hole
Mount Through Hole
