50009-5120D
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
HPC? Non-RoHS Compliant COMMERCIAL UL CSA Connector Header, Male Pins UL94V-0 20mOhm 125C 1A
PDF
/
Inventory: 8763
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating GXT, Gold
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Technical
Packaging Tube
Series HPC?
Feature Mating Guide
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 120
Color Black
Number of Rows 4
Additional Feature OPTIONAL POLARIZATION, FMLB
Subcategory Headers and Edge Type Connectors
Pitch 0.100 2.54mm
Total Number of Contacts 120
Orientation Straight
Depth 14.86mm
Number of Positions Loaded All
Number of Conductors ONE
Reference Standard UL, CSA
Contact Finish Gold or Gold, GXT?
Reliability COMMERCIAL
Number Of PCB Rows 4
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 125°C
Body Breadth 0.585 inch
Operating Temperature (Min) -65°C
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Insulation Resistance 1000000000Ohm
Body/Shell Style RECEPTACLE
Polarization Key POLARIZED KEY
Dielectric Withstanding Voltage 1000VAC V
Connector Style High Density (HDC, HDI, HPC)
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.1 inch
Number of Columns 30
Connector Usage Daughtercard
Dimensions
Length 95.3mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness FLASH inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
