10113947-E0C-70B
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
XCede? Non-RoHS Compliant GENERAL PURPOSE Key Connector Header, Male Pins and Blades UL94V-0 -55C~85C 30.0muin 0.76mum
PDF
/
Inventory: 4799
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating GXT, Gold
Mount Through Hole
Mounting Type Through Hole
Number of Pins 24
Technical
Operating Temperature -55°C~85°C
Packaging Bulk
Series XCede?
JESD-609 Code e0
Feature Key
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Header, Male Pins and Blades
Color Gray
Additional Feature POLARIZED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Number of Positions Loaded All
Contact Finish Gold or Gold, GXT?
UL Flammability Code 94V-0
Connector Style XCede?, Guide Left
Contact Layout, Typical 18 Differential Pairs
Number of Columns 6
Connector Usage Backplane
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
