10106134-4009101LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Inventory: 7776
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.135 inch
Technical
Contact Arrangement S36P4
Withdrawl Force-Min .1668 N
Insertion Force-Max 1.0008 N
Durability 500 Cycles
Termination Type SOLDER
Body/Shell Style RECEPTACLE
Insulation Resistance 500000000Ohm
Contact Resistance 20mOhm
Contact Style HYBRID
Body Depth 0.82 inch
Operating Temperature (Min) -40°C
Contact Gender MALE
Body Breadth 0.47 inch
Operating Temperature (Max) 125°C
Body Length or Diameter 2.165 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 40
Mixed Contacts YES
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Physical
Board Mounting Option HOLE .112-.124
Mounting Style RIGHT ANGLE
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED THERMOPLASTIC
Mounting Type BOARD
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 9 Weeks
