HDC-S276-32S1-TG30
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
HDC (High Density Connector) Non-RoHS Compliant 2013 Gold Connector Receptacle, Female Sockets UL94V-0 125C 3A 30.0muin 0.76mum
PDF
/
Inventory: 8339
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole, Right Angle
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series HDC (High Density Connector)
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Receptacle, Female Sockets
Number of Positions 276
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 3
Current Rating (Amps) 3A
Pitch 0.100 2.54mm
Number of Positions Loaded All
Contact Finish Gold
Connector Style High Density (HDC, HDI, HPC)
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
