926040-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Housings
Description
CONN DIN RECEPT 48POS VERT PCB
PDF
/
Buying Options
Total Price: USD $5.09
Unit Price: USD $5.0864
≥1 USD $5.0864
≥10 USD $4.43696
≥100 USD $4.320096
≥500 USD $4.203232
≥1000 USD $4.111096
Inventory: 1241
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polycarbonate
Technical
Packaging Bulk
Published 1998
Series AMPMODU Mod IV
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Housing for Female Sockets
Number of Positions 48
Max Operating Temperature 105°C
Min Operating Temperature -65°C
Number of Rows 3
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Pitch 0.100 2.54mm
Total Number of Contacts 48
Orientation Straight
Depth 13.5mm
Current Rating 1.5A
Reference Standard UL, CSA
Reliability COMMERCIAL
Number Of PCB Rows 3
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-1
Housing Color Grey
Rated Current (Signal) 1A
Contact Resistance 15mOhm
Insulation Resistance 1000000000000Ohm
Note Contacts Not Included
Max Voltage Rating (AC) 250V
Dielectric Withstanding Voltage 250VAC V
Wire/Cable Type Discrete
Connector Style DIN 41612, Type C
PCB Contact Row Spacing 2.54 mm
Insulator Color GRAY
Connector System Wire-to-Board
Connector Usage Receptacle
Mating Alignment With
Dimensions
Height 10.06mm
Length 54.4mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
