MP2-HS192-41
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Housings
Description
High Speed / Modular Connectors 192P/4R/MP2 HRD/SHRD/3.50MM
PDF
/
Inventory: 5294
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Insulation Material GLASS FILLED LIQUID CRYSTAL POLYMER
Technical
Packaging Bulk
Published 2003
Series MetPak? MP2
Feature Standoffs
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Shroud for Male Pins
Number of Positions 192
Number of Rows 4
Additional Feature NONE
Subcategory Headers and Edge Type Connectors
Pitch 0.079 2.00mm
Total Number of Contacts 192
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 3.778 inch
Number Of PCB Rows 4
PCB Contact Pattern RECTANGULAR
Body Breadth 0.622 inch
Body Depth 0.669 inch
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Insulation Resistance 1000000000Ohm
Note Contacts Not Included
Body/Shell Style RECEPTACLE
Dielectric Withstanding Voltage 1500VAC V
PCB Contact Row Spacing 2.0066 mm
Durability 500 Cycles
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.079 inch
Compliance
RoHS Status RoHS Compliant
