100145-9
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Hard Metric, Standard
Description
CONN 2MM HM RCPT 125POS R/A GOLD
PDF
/
Inventory: 6820
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length - Termination 0.13 inch
Plating Thickness 30μin
Technical
Insulator Color GRAY
Mating Contact Row Spacing 0.079 inch
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 2.0066 mm
ELV Non-Compliant
Body/Shell Style PLUG
Contact Resistance 20mOhm
Contact Style BELLOWED TYPE
Housing Color Grey
UL Flammability Code 94V-0
Body Breadth 0.449 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 125
Number Of PCB Rows 5
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 1.5A
Shielding Unshielded
Orientation Right Angle
Pitch 2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature ACTION PIN
Voltage - Rated 500V
Gender Female
Number of Rows 5
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type Connector, Receptacle
ECCN Code EAR99
Termination Solder
Physical
PCB Mounting Orientation Right Angle
Housing Material Polyester
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
