0850420074
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - DIN 41612
Description
Conn DIN 41612 F 48 POS 2.54mm Solder ST Thru-Hole Tray
PDF
/
Inventory: 3565
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 24.0μin 0.61μm
Length 55mm
Technical
Level, Class 2
Max Voltage Rating (AC) 1kV
Number of Circuits 32
Contact Finish Gold
Current Rating 2.5A
Number of Positions Loaded 32
Style C/2 (1/2 C)
Depth 10.5mm
Orientation Vertical
Pitch 0.100 2.54mm
Number of Rows 3
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 48
Connector Type Receptacle, Female Sockets
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 85042
Packaging Tray
Operating Temperature -55°C~125°C
Physical
Material - Insulation Polyester Thermoplastic
Housing Material Polyester
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 9 Weeks
