0850037067
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - DIN 41612
Description
DIN 41612 Connectors DINCONN. C MALE 96CK CKT CLP HT 850037067
PDF
/
Inventory: 5539
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Length 94mm
Technical
Max Voltage Rating (AC) 250V
Number of Circuits 48
Contact Resistance 20mOhm
Housing Color Natural
UL Flammability Code 94V-0
Contact Finish Gold
Current Rating 1A
Number of Positions Loaded All
Style C
Depth 18.08mm
Orientation Right Angle
Total Number of Contacts 96
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance YES
DIN Conformance YES
MIL Conformance NO
Number of Rows 3
Number of Positions 96
Connector Type Header, Male Pins
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Mounting Clips
Series 85003
Packaging Tray
Operating Temperature -55°C~125°C
Physical
Material - Insulation Polyester Thermoplastic
Housing Material Polyester
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Brass
Supply Chain
Factory Lead Time 10 Weeks
