0850019010
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - DIN 41612
Description
85001 ROHS3Compliant Right Angle GENERAL PURPOSE DIN Connector UL94V-0 -55C~125C 1A 24.0muin 0.61mum
PDF
/
Inventory: 2905
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 24.0μin 0.61μm
Technical
Housing Color Natural
Contact Finish Gold
Current Rating 1A
Reach Compliance Code unknown
Number of Positions Loaded 8
Style B/2 (1/2 B)
Orientation Right Angle
Total Number of Contacts 8
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance YES
DIN Conformance YES
MIL Conformance NO
Number of Rows 2
Number of Positions 32
Connector Type Header, Male Pins
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Mounting Clips
JESD-609 Code e3
Series 85001
Packaging Tray
Operating Temperature -55°C~125°C
Physical
Material - Insulation Polyester Thermoplastic
Housing Material Polyester
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Brass
Supply Chain
Factory Lead Time 16 Weeks
