09281487907
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - DIN 41612
Description
DIN 41612 ROHS3Compliant COMMERCIAL VDECSA DIN Connector 1.5568N 15mOhm -55C~125C 2A
PDF
/
Inventory: 9874
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Through Hole
Material - Insulation Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series DIN 41612
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 48
Number of Rows 3
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance YES
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 2A
Pitch 0.100 2.54mm
Total Number of Contacts 48
Style 2R
Number of Positions Loaded All
Reference Standard VDE,CSA
Contact Finish Gold-Palladium
Reliability COMMERCIAL
Body Length or Diameter 2.165 inch
Number Of PCB Rows 3
PCB Contact Pattern RECTANGULAR
UL Flammability Code 94V-0
Body Depth 0.457 inch
Contact Resistance 15mOhm
Insulation Resistance 1000000000000Ohm
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 1000VAC V
PCB Contact Row Spacing 2.54 mm
Insertion Force-Max 1.5568 N
Withdrawl Force-Min 1.5568 N
Mating Contact Row Spacing 0.1 inch
Name of Rows Loaded A,B,C
Dimensions
Contact Finish Thickness Flash
Length - Termination 0.512 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
