122A10789X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - DIN 41612
Description
ROHS COMPLIANT DIN Connector
PDF
/
Inventory: 2287
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material COPPER ALLOY
Mount Through Hole
Mounting Type Through Hole, Right Angle
Material - Insulation Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Female Sockets
Number of Positions 48
Number of Rows 3
Additional Feature ROHS COMPLIANT
Subcategory Headers and Edge Type Connectors
DIN Conformance YES
Pitch 0.100 2.54mm
Total Number of Contacts 16
Style C/2 (1/2 C)
Number of Positions Loaded 16
Current Rating 2A
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Body Breadth 0.417 inch
Rated Current (Signal) 2A
Contact Resistance 20mOhm
Insulation Resistance 100000000Ohm
Polarization Key POLARIZED HOUSING
PCB Contact Row Spacing 5.08 mm
Durability 50 Cycles
Mating Contact Row Spacing 0.2 inch
Name of Rows Loaded A,C
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
