121A10659X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - DIN 41612
Description
ROHS COMPLIANT DIN Connector
PDF
/
Inventory: 1602
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.146 inch
Technical
Name of Rows Loaded A,C
Level, Class 3
Durability 50 Cycles
PCB Contact Row Spacing 5.08 mm
Insulation Resistance 100000000Ohm
Contact Resistance 15mOhm
Rated Current (Signal) 5.5A
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Current Rating 2A
Number of Positions Loaded 16
Style D
Total Number of Contacts 16
Pitch 0.200 5.08mm
DIN Conformance YES
Additional Feature ROHS COMPLIANT
Number of Rows 2
Number of Positions 32
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Material - Insulation Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 12 Weeks
