121A10599X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - DIN 41612
Description
ROHS COMPLIANT DIN Connector
PDF
/
Inventory: 7568
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.512 inch
Technical
Name of Rows Loaded A,B,C
Mating Contact Row Spacing 0.1 inch
Durability 50 Cycles
PCB Contact Row Spacing 2.54 mm
Polarization Key POLARIZED HOUSING
Insulation Resistance 100000000Ohm
Contact Resistance 20mOhm
Rated Current (Signal) 2A
Body Depth 0.457 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 3
Body Length or Diameter 2.165 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Current Rating 2A
Number of Positions Loaded All
Style R/2 (1/2 R)
Total Number of Contacts 48
Pitch 0.100 2.54mm
DIN Conformance YES
Subcategory Headers and Edge Type Connectors
Additional Feature ROHS COMPLIANT
Number of Rows 3
Number of Positions 48
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2015
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Material - Insulation Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
