121A10169X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - DIN 41612
Description
DIN Connector
PDF
/
Inventory: 2767
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Material - Insulation Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header, Male Pins
Number of Positions 96
Number of Rows 3
DIN Conformance YES
Total Number of Contacts 32
Terminal Pitch 5.08mm
Style C
Number of Positions Loaded 32
Current Rating 2A
Reference Standard UL
Contact Finish Gold
Number Of PCB Rows 2
Rated Current (Signal) 2A
Contact Resistance 20mOhm
Insulation Resistance 100000000Ohm
Polarization Key POLARIZED HOUSING
PCB Contact Row Spacing 5.08 mm
Name of Rows Loaded A,C
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
