DIN-032RPE-DPS-KR
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - DIN 41612
Description
DIN 41612 RoHS Compliant 2010 Gold DIN Connector -55C~125C 3A 30.0muin 0.76mum
PDF
/
Inventory: 8621
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Through Hole
Number of Pins 32
Material - Insulation Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2010
Series DIN 41612
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Plug, Male Pins
Number of Positions 96
Number of Rows 3
Current Rating (Amps) 3A
Pitch 0.100 2.54mm
Style R
Number of Positions Loaded 32
Contact Finish Gold
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
