2101003-1 image
Favorite
2101003-1 image
Favorite
RoHS
/
Package Metal
Category Connectors, Interconnects / Backplane Connectors - ARINC
Description ARINC Connector
PDF
/
Inventory: 7463
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Radiation Hardening No

Technical

Cavity D 150
Cavity F 13C2
Cavity E 150
Cavity B 150
Cavity C 13C2
Cavity A 150
Shell Style Receptacle
Polarized Yes
Class Code 1A
Shell Plating Chromate
Preloaded Yes
Sealable No
Shell Size 3
ELV Non-Compliant
Note Partially Loaded
Orientation Straight
Gender Female
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Connector Type Socket
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Cinch Nuts (M3), Dust Cap
Series 600
Published 2016
Packaging Bulk

Physical

Package / Case Metal
Mount Through Hole
Contact Plating Gold

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 10 Weeks
