TY-303P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
TRIAD MAGNETICS TY-303P Audio Transformer, Data / Voice Coupling, 0 mA, 600 ohm, 4 kohm, Through Hole
PDF
/
Buying Options
Total Price: USD $4.56
Unit Price: USD $4.5584
≥1 USD $4.5584
≥10 USD $3.4672
≥100 USD $3.376032
≥500 USD $3.102176
≥1000 USD $2.919752
≥3000 USD $2.828531
Inventory: 525
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 18.2mm
Length 20.62mm
Height Seated (Max) 0.740 18.80mm
Height 18.8mm
Technical
Power Level -45dB~7dB
DC Resistance (DCR) - Secondary 52Ohm
DC Resistance (DCR) - Primary 260Ohm
Impedance - Secondary (Ω) 600
Frequency Response ±0.5dB
Impedance - Primary (Ω) 4k
Return Loss 26dB Typ
Turns Ratio - Primary:Secondary 2.43:1
Transformer Type Data/Voice Coupling
Insertion Loss (dB) 1 dB
Insertion Loss 1dB Typ
Frequency Range 300Hz~3.5kHz
Voltage - Isolation 1500VAC
Termination Style PC Pin
Frequency 4kHz
Current Rating 0A
Min Operating Temperature 0°C
Max Operating Temperature 105°C
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 0.812Lx0.715W 20.62mmx18.16mm
Series TY
Published 2011
Packaging Bulk
Operating Temperature -20°C~85°C
Physical
Weight 23.586803g
Number of Pins 4
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 17 Weeks
Alternative Model
