SP-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
Audio Transformer - More Details
PDF
/
Buying Options
Total Price: USD $9.71
Unit Price: USD $9.7064
≥1 USD $9.7064
≥10 USD $9.19952
≥100 USD $8.756
Inventory: 74
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Number of Pins 6
Weight 11.339809g
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series Red-Spec
Size / Dimension 0.410Lx0.310W 10.41mmx7.87mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
Power Rating 10mW
Voltage - Rated DC 150V
Current Rating 0A
Frequency 100kHz
Termination Style PC Pin
Voltage - Isolation 1000VRMS @ 1 Second
DC Resistance (DCR) 5.3kOhm
Output Power 10mW
Max Frequency 100kHz
Frequency Range 300Hz~100kHz
Transformer Type Audio Coupling
Turns Ratio - Primary:Secondary 14.1:1
Impedance - Primary (Ω) 200kCT
Frequency Response ±2dB
Impedance - Secondary (Ω) 1kCT
DC Resistance (DCR) - Primary 5.3kOhm
DC Resistance (DCR) - Secondary 100Ohm
Power Level 10mW
Dimensions
Height 11.811mm
Height Seated (Max) 0.465 11.80mm
Length 10.41mm
Width 10.4mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
