TTC-5024
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
TRANSFORMER MODEM 600:330OHM SMD
PDF
/
Buying Options
Total Price: USD $8.52
Unit Price: USD $8.516782
≥1 USD $8.516782
≥200 USD $3.399098
≥400 USD $3.284876
≥800 USD $3.228421
Inventory: 1236
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Number of Pins 6
Technical
Operating Temperature -20°C~85°C
Packaging Tape & Reel (TR)
Published 2004
Series TTC
Size / Dimension 0.378Lx0.492W 9.60mmx12.50mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Flat
Termination Style Flat Lead
Approval Agency UL60950, EN60950
Voltage - Isolation 1875VRMS @ 1 Second
Frequency Range 200Hz~4kHz
Insertion Loss 3dB Max @ 2kHz
Insertion Loss (dB) 3 dB
Transformer Type Data/Voice Coupling
Turns Ratio - Primary:Secondary 1:1
Return Loss 16dB Min @ 200Hz ~ 4kHz
Impedance - Primary (Ω) 600
Frequency Response ±0.2dB
Impedance - Secondary (Ω) 330
DC Resistance (DCR) - Primary 150Ohm
DC Resistance (DCR) - Secondary 150Ohm
Dimensions
Height Seated (Max) 0.299 7.60mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
Alternative Model
