TTC-5003
RoHS
/
Package /
Category Transformers / Audio Transformers
Description
GLOVE, POLYAMIDE, L/FREE, PU, SIZE 6 - More Details
PDF
/
Inventory: 5379
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Number of Pins 10
Technical
Packaging Tape & Reel (TR)
Published 2002
Series TTC
Size / Dimension 0.532Lx0.551W 13.50mmx14.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Termination Style Gull Wing
Approval Agency UL1950, UL60950
Voltage - Isolation 1875VRMS @ 1 Second
Frequency Range 200Hz~4kHz
Insertion Loss 3.2dB Max @ 1kHz
Insertion Loss (dB) 3.2 dB
Transformer Type Data/Voice Coupling
Turns Ratio - Primary:Secondary 1:1
Return Loss 18dB Min @ 200Hz ~ 4kHz
Impedance - Primary (Ω) 600
Frequency Response ±0.25dB
Impedance - Secondary (Ω) 320
DC Resistance (DCR) - Primary 115Ohm
DC Resistance (DCR) - Secondary 145Ohm
Dimensions
Height 10.4mm
Height Seated (Max) 0.409 10.40mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
