TTC-13
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
TRANSF TELE COUP 4000:600 0 MADC
PDF
/
Buying Options
Total Price: USD $7.26
Unit Price: USD $7.264276
≥1 USD $7.264276
≥200 USD $2.898883
≥560 USD $2.801729
≥1120 USD $2.754464
Inventory: 1077
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 16.5mm
Length 20.3mm
Height Seated (Max) 0.736 18.70mm
Technical
Power Level -45dB~7dB
DC Resistance (DCR) - Secondary 45Ohm
DC Resistance (DCR) - Primary 225Ohm
Impedance - Secondary (Ω) 600
Frequency Response ±0.5dB
Impedance - Primary (Ω) 4k
Number of Primary Winding 1
Number of Secondary Winding 1
Turns Ratio - Primary:Secondary 1:0.397
Transformer Type Data/Voice Coupling
Insertion Loss (dB) 0.9 dB
Operating Frequency-Min 0.3kHz
Insertion Loss 1.2dB Max @ 1kHz
Operating Frequency-Max 3.5kHz
Frequency Range 300Hz~3.5kHz
Application SIGNAL
Voltage - Isolation 1500VRMS @ 1 Minute
Physical Dimension 20.32mm x 16.5mm x 18.7mm
Approval Agency CSA-C22.2 No. 66-M1988, UL1459
Termination Style PC Pin
Reach Compliance Code unknown
Subcategory Other Transformers
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.799Lx0.650W 20.30mmx16.50mm
Series TTC
Published 2006
Packaging Bulk
Physical
Number of Pins 4
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 20 Weeks
